Manufacturing range as follows:
Code: API 650, BS, IS.
Type: Conical Roof, Flat Bottom
Diameter: 4000 mm
Length: 5000 mm.
Thickness: 12 mm.
Weight: 10 MT.
Design Pressure: 0.5 Kg/cm2 g/ Partial vacuum.
Design Temperature: 100 ℃
MOC: Carbon Steel, Stainless Steel, Carbon Steel with Rubber lining.
Some of our major storage tanks orders, with design data are listed below:
|
CLIENT |
ORDER NO. |
QTY |
CODE |
DESC. |
PRESSURE kg/cm2 g |
TEMP ℃ |
MOC |
SIZE |
WEIGHT |
INSPECTION |
| HWP- BARC, Hazira | 77905 | 1 | ASME, SECT VIII, DIV-1 | Heavy water storage tank | 3 | 100 | SS 304 L | 2600 x 5200 x 10 | 4.2 | BARC |
| NCPL, TDI Project, Bharuch | 60150 | 1 | API 650 | 85% AN Melt tank | ATM | 110 | SS 304 L | 2700 x 3000 x 6 | 3.2 | IBIC |
| GACL, Dahej | 510/ 166 | 1 | API 650 | 98% H2SO4 Tank | ATM | 60 | IS 2062- B | 4000 x 4500 x 10/12 | 7.5 | GACL |
| NCPL, TDI Project, Bharuch | 10046 | 1 | API 650 | Diesel Oil tank | 0.1 | 50 | IS 2062- B | 3000 x 3600 x 6/8 | 2.9 | IBIC |
