Manufacturing range as follows:
Code: ASME, BS, IS.
Type: Plain, Jacketted, Limpet Coil, Internal Coil.
Supports: Leg, Lug.
Diameter: 2000 mm.
Length: 3500 mm.
Thickness: 20 mm.
Weight: 15 MT.
Design Pressure: 10 Kg/cm2 g, Full Vacuum.
Design Temperature: 200 ℃
Agitator: Turbine, Propeller, Anchor type upto 30 HP, 300 RPM with Gland Packing or Mechanical Seal.
MOC: Carbon Steel, Stainless Steel, Alloy Steel, Low Temperature Carbon Steel.
Some of our major reactors orders, with design data are listed below:
|
CLIENT |
ORDER NO. |
QTY |
CODE |
DESC. |
PRESSURE kg/cm2 g |
TEMP ℃ |
MOC |
SIZE (dia x length x thk) |
WEIGHT MT |
INSPECTION |
| NCPL, TDI Project, Bharuch | 60150 | 1 | API 650 | Int. reactor tank, 5 HP agitator. | 1 | 150 | SS 316 L | 2300 x 2100 x 6 | 6.2 | IBIC |
| Patcham, Sharjah | LCP- 026 | 1 | API 650 | 4 KL dilution tank, 20 HP agitator. | ATM | 80 | SS 304 L | 1700 x 2100 x 6/8 | 3.1 | PATCHAM |
| NCPL, TDI Project, Bharuch | 60150 | 1 | API 650 | Wash water mixing tank with 5 HP agitator, internal coil. | ATM | 120 | SS 316 L | 2300 x 2500 x 5/6 | 3.1 | IBIC |
