Manufacturing range as follows:


Code: ASME, BS, IS, DIN

Type: Plain, Jacketted, Limpet Coil, Internal Coil.

Supports: Leg, Lug, Saddle.

Diameter: 3000 mm

Length: 13000 mm.

Thickness: 25 mm.

Weight: 28 MT.

Design Pressure: 75 Kg / cm2 g & Full Vacuum

Design Temperature: 450 ℃

MOC: Carbon Steel, Stainless Steel, Alloy Steel, Low Temperature Carbon Steel,

Carbon Steel Rubber and Lead lined.

Some of our major pressure vessel orders, with design data are listed below:


CLIENT

ORDER NO.

QTY

CODE

DESC.

PRESSURE kg/cm2 g

TEMP

MOC

SIZE
(dia x length x thk)

WEIGHT
MT

INSPECTION

Daelim, South Korea

020313-1200-202

15

ASME, SECT VIII, DIV-1, IBR

Vessels

FV-50

150- 300

A516 GR 70

574-3900 x
3000-11000
X
8-22

1.20 - 27.5

Lloyds, Jacob.

GSFC Amm. Project., Vadodara

1034

3

ASME, SECT VIII, DIV-1

Inst. Air Receiver Separator

23

-5 -
+130

A516 GR 70

500-
3000
x
2000-
5700
x
8 - 16

0.6 - 13.0

Linde, TICB.

GSFC Caprolactam, Vadodara

M-044, 046, 018

11

ASME, SECT VIII, DIV-1

Separator, Expanders, Seal Pot

2-12

75 - 200

A240TP316L, A240TP321, A240304L, A515 Gr. 60

500-
2000
x
1500-
2400
x
4 - 8

1.5 - 3.8

UHDE.

IPCL, Dahej

Various

154

ASME, SECT VIII, DIV-1, IBR

Tank Vessels with Agitators, Heaters

FV – 66

-168 – +420

A516 GR 70
A240 TP 304
CSRL

200-4000
x
2500-7800
x
8-28

1.2-8.9

EIL, IBR, UHDE.

Farabi  Petrochemicals Co, Saudi Arabia

OK-3013B

13

ASME, SECT VIII, DIV-1

Vessels

FV - 34.5

185

A516 GR 70
A240 TP 304

400- 2600
x
600- 7800
x
3-22

1 - 16

UHDE.

RIL PBR III, Hazira

7400152

11

ASME, SECT VIII, DIV-1

Vessels & Reactors

FV - 5

200

A516 GR 70

400- 2500
x
800- 6550
x
6- 16

0.5 - 7.3

IRS, TOYO.

Lanxess, Jhagadia

209578

1

ASME, SECT VIII, DIV-1

Nitrogen Buffer Vessel

FV- 10

200

A516 GR 70

3000 x 4700 x 16/22

10.8

UHDE
