Manufacturing range as follows:
Code: ASME, TEMA, EJMA.
Type: Fixed Tube Sheet, Floating Head, U-Tube, Kettle, Pipe to Pipe, with Expansion Joints and Bellows.
Supports: Lug, Saddle.
Tubes (Nos. x Length x OD): 1400 x 8500 mm x 50.8 mm
Tube Sheet: 1800 mm dia X 140 mm thk.
Design Pressure: 30 Kg/cm2 g, Full Vacuum.
Design Temperature: 240 ℃
Weight: 29 MT.
MOC: Carbon Steel, Stainless Steel, Low Temperature Carbon Steel.
Tube Materials: Carbon Steel, Stainless Steel, Copper, Cupro-Nickel, Brass.
Some of our major heat exchangers orders, with design data are listed below:
|
CLIENT |
ORDER NO. |
QTY |
DESC. |
CODE |
PRESSURE kg/cm2 g |
TUBESHEET |
DESIGN TEMP °C |
NO. OF TUBES |
WT (mt) |
INSPECTION |
|||
| SHELL | TUBE | MOC | THK (MM) | SHELL | TUBE | ||||||||
| RIL, Nagothane | NM3/7015098 | 1 | Deethanizer Bottom Reboiler | ASME/ TEMA-R | 25 | 17.5 | A350 LF2 | 80 | -25/ 85 | 105 | 800 | 11.6 | IRS |
| RIL, Vadodara | BM2/ 3480739 | 1 | Condenser | ASME/ TEMA-R | 21 | 9 | A516-70 | 58 | 100 | 50 | 610 | 14.7 | IRS |
| RIL, Dahej | GMI/ 7071659 | 1 | Wash Water Cooler | ASME/ TEMA-R | 30 | 23 | A336 F 304L | 115 | 80 | 65 | 1234 | 27.5 | TUV/ Jacob |
| RIL, Nagothane | NM3/ 7090199 | 1 | Tube Bundle | ASME/ TEMA-R | 24.5 | 36.6 | A266 CL2 | 136 | 223 | 80 | 1366 | 21.9 | BVIS |
| RIL Butene Proj. Hazira | 7255472 | 8 | Cooler, Condenser- Type AES & AEM | ASME Sec VIII Div 1, TEMA-R | FV- 24 | FV- 18.5 | A266 CL2 | 70 | -8/ 149 | -5/ 164 | 102- 496 | 1.4 - 6.6 | BVIS |
| GNFC, Bharuch | 210689 | 1 | Gas Cooler | IBR, TEMA-R, ASME Sec VIII Div 1 | 5.6 | 23 | A182F304 | 68 | 300 | 180 | 496 | 4 | IBR, Lloyds |
| GSFC, Methanol, Vadodara | 5625 | 1 | Conc. Col. Steam Reboiler (BKU) | TEMA-R, ASME Sec VIII Div 1 | FV- 5 | FV- 7 | A266 CL2 | 55 | 160 | 205 | 143 U | 4.5 | PDIL |
| KRIBHCO, Hazira | 29661 | 1 | Chiller Unit for Air Compressor | TEMA-R, ASME Sec VIII Div 1 | NA | 8 | NA | NA | NA | 45 | 100 SPWD finned tubes | 2.5 | KRIBHCO |
